Description
PHYSICAL
Size (W x H x D) mm – Main
360 X 58 X 298.5
Size (W x H x D) mm – Front Speaker
250x1100x250
Size (W x H x D) mm – Center Speaker
260x93x73
Size (W x H x D) mm – Rear Speaker
88x122x81
Size (W x H x D) mm – Subwoofer
191x386x318
Size (W x H x D) mm – Freight (20ft/40ft/40ft HC)
234/480/560
AMPLIFIER
CH
5.1
POWER OUTPUT – Total
1000W
THD 10% – Front L/R
167WX2
(3?:sat/3?:subwoofer) – Center
167W
(3?:sat/3?:subwoofer) – Surround L/R
167WX2
(3?:sat/3?:subwoofer) – Sub-Woofer
167W(Passive)
DESIGN(MAINSET)
Uni-body (Tray)
No
Top & Bottom cabinet (Tray)
No
Front & Rear cabinet (tray)
Yes
CONNECTIVITY
Wired (Ethernet)
No
HOME MENU
Cre-editable
No
Home Dashboard
No
Home Menu
Yes
IN & OUT
Front – Display
FLD
Front – USB
1
Front – Mic – Mic In(?6.3)
2
Front – Audio In – Portable In
Yes
CONVENIENCE
Multi-tasking
No
Smart phone remote App
No
Magic Remote Control
No
SIMPLINK
No
Instant tray open – Booting Time
No
Warm booting
No
Booting Time
No
Loading Time
No
Firmware update by network
No
Speaker Level Trim
Yes
Speaker Distance (channel delay)
Yes
Test Tone
Yes
Mute
Yes
A/V Sync Delay(Audio Delay)
Yes
Dimmer
Yes
Sleep
Yes
Volume on TV
Yes
USB Direct Recording
Yes
External HDD Playback
No
TV Sound (direct key) / TV Sound connect (Auto PWR on/off by optical)
Yes / No
Dynamic Range Control – On/Off
Yes
Meta Data Showing GraceNote (CD/Streaming/File)
No
Progress Bar
No
Cinema zoom
Yes
Thumbnail – Movie/Photo
Yes
Wireless Speaker – 1:3 Speaker Built-in Type (Front / Subwoofer)
No
(Tx dongle Type) – 1:2 Speaker Built-in Type (Rear)
No
(Tx dongle Type) – 1:1 Rx module Type (Wireless Kit for rear)
No
(Tx dongle Type) – 1:1 Rx + Wireless Sub-woofer (3ch wireless)
No
(Tx dongle Type) – 1:1 RX for Subwoofer
No
Bluetooth (Rx / Tx)
Yes / No
Karaoke – Mic Volume / Echo Volume
Yes
Karaoke – Fanfare
Yes
Karaoke – Scoring
Yes
Karaoke – Real Time Scoring
No
Karaoke – Howlling Canceller
Yes
Karaoke – CD Voice Remover
Yes
SOUND DSP
DSP
No
DISC & AV FORMAT
Playable – BD-ROM
No
Disc Type – BD-R
No
Disc Type – BD-RE
No
Disc Type – Hybrid Disc (BD+DVD)
No
Disc Type – DVD(NTSC)
Yes
Disc Type – DVD(PAL)
Yes
Disc Type – DVD-R
Yes
Disc Type – DVD-RW(Video/VR Mode)
Yes / No
Disc Type – DVD+R
Yes
Disc Type – DVD+RW(Video mode)
Yes
Disc Type – DVD-RAM
No
Disc Type – DVD-Audio
No
Disc Type – Video CD/Super VCD
Yes / Yes
Disc Type – Audio CD
Yes
Disc Type – DTS-CD
No
Disc Type – SACD
No
Disc Type – CD-R/CD-RW
Yes
Video Format – MPEG2
Yes
Video Format – MPEG4 AVC (H.264)
No
Video Format – SMPTE VC1 (VC-9)
No
Video Format – Xvid
Yes
Video Format – MKV
No
Video Format – AVC Rec
No
Video Format – AVCHD
No
Video Format – M4V
No
Video Format – RMVB
No
Video Format – WMV
No
Video Format – FLV
No
Video Format – 3GP
No
Video Format – MPEG-1
No
Video Format – K3G
No
Video Format – MP4
No
Video Format – MOV
No
Video Format – VOB
No
Audio Format (Decoding) – LPCM
LPCM
Audio Format (Decoding) – Dolby Pro Logic II
No
Audio Format (Decoding) – Dolby Digital
Yes
Audio Format (Decoding) – Dolby Digital Plus
No
Audio Format (Decoding) – Dolby TrueHD
No
Audio Format (Decoding) – DTS
No
Audio Format (Decoding) – DTS-HD High Resolution Audio
No
Audio Format (Decoding) – DTS-HD Master Audio
No
Audio Format (Decoding) – DTS2.0+Digital Out
No
Audio Format (Decoding) – MPEG 1/2 L2
Yes
Audio Format (Decoding) – MP3 – ID3 Tag
Yes/Yes
Audio Format (Decoding) – FLAC
No
Audio Format (Decoding) – WMA
Yes
Audio Format (Decoding) – AAC
No
Graphics / Subtitle Format
2bit / 8bit Sub-picture
Text-based Subtitle
Video – GUI/ Menu – Language
Option
Features – Video DAC
148MHZ/12bit
Features – NTSC/PAL Hz
60Hz / 50Hz
Features – NTSC/PAL Hz – Resolution
upto 1080p 24 / 60Hz
Features – VBI – WSS/CGMS-A/Closed Caption/Macrovsion
Yes
Features – NTSC?PAL Conversion
Yes
Features – HDMI 1.4
No
Features – ARC
No
Features – Deep Colour
No
Features – xvYCC
No
Features – Last Scene memory
Yes
Features – Photo Zoom
No
Features – Video Enhancement
No
DISC(BD, DVD, CD)PLAYBACK SPECIFICATION
General – Screen Saver
Yes
Auto Power Off
Yes
Parental Lock
Yes
Initial logo
Yes
BD – MHP-Like Interactivity
No
BD – Simultaneous Playback of HD & SD Video Drip
No
BD – BD ROM profile
No
BD – Still Picture
No
BD – Digital Cinema 4K upscaling
No
DVD – 1080p Upscaling
Yes
Trick Play – Fast Forward – DVD, CD-DA, MP3/WMA
Yes
Trick Play – Fast Back – DVD, CD-DA, MP3/WMA
Yes
Trick Play – Fast Slow – DVD
Yes
Trick Play – Reverse Slow
Yes
Trick Play – Pause – DVD, CD-DA, MP3/WMA
Yes
Trick Play – Pause – Forward Step – DVD
Yes
Trick Play – Pause – Reverse Step
No
Search – Title/Track – DVD, CD-DA, MP3/WMA
Yes
Search – Chapter – DVD
Yes
Search – Time – DVD
Yes
Repeat Play – Title/Track – HDMV, DVD, CD-DA, MP3/WMA
Yes
Repeat Play – Chapter – HDMV, DVD
Yes
Repeat Play – A-B – HDMV, DVD(-VR)
No
Resume Stop – DVD, CD-DA,MP3/WMA
Yes
Play Mode – Program – DVD, CD-DA,MP3/WMA
No
Play Mode – Random – CD-DA, MP3/WMA
Yes
Marker Search – 9 Points – DVD
No
Marker Play – CD-DA, MP3/WMA
Yes
POWER
Power – SMPS
Option
Power – Power Off Consumption
0.5W ?
Power – Power Consumption
145W
RADIO
Tuner Type
PLL
Tuning Up/Down
Yes
Preset Up/Down
Yes
Band FM / FM(RDS) / AM
Yes / No / No
Preset Memory
50 Station
RDS (PS, PTY, CT, RT)
No
SPEAKER
Including Speaker – Front – Model Name
S67T2-S
Including Speaker – Front – SPL
81dB
Including Speaker – Front – System
Closed Type
Including Speaker – Front – Woofer Unit
3? Paper
Including Speaker – Front – Impedance
3?
Including Speaker – Front – Magnetic Shielding
Non-Shielded
Including Speaker – Rear – Model Name
S67S2-S
Including Speaker – Rear – SPL
81dB
Including Speaker – Rear – System
Closed Type
Including Speaker – Rear – Woofer Unit
3? Paper
Including Speaker – Rear – Impedance
3?
Including Speaker – Rear – Magnetic Shielding
Non-Shielded
Including Speaker – Center – Model Name
S67T2-C
Including Speaker – Center – SPL
79.0dB
Including Speaker – Center – System
Closed Type
Including Speaker – Center – Woofer Unit
3? Paper
Including Speaker – Center – Impedance
3?
Including Speaker – Center – Magnetic Shielding
Non-Shielded
Including Speaker – Subwoofer – Model Name
S67T2-W
Including Speaker – Subwoofer – SPL
83dB
Including Speaker – Subwoofer – System
Bass Reflex
Including Speaker – Subwoofer – Woofer Unit
7? Paper
Including Speaker – Subwoofer – Impedance
3?
Including Speaker – Subwoofer – Magnetic Shielding
Non-Shield
Including Speaker – Rear Wireless Kit – Name
No
FEATURE LIST & ACCESSORY KIT
Instruction Manual
Printing Book
Instruction Manual – Simple Manual
Yes
Remote Control Unit Type
CB1
Remote Control Unit – MBR
No
Remote Control Unit Unified
No
Remote Control Unit Battery(Size)
AAA*1
Batteries (Remote Controller)
Yes
FM / AM Antenna
Yes / No
Speaker Cable
Yes (5EA)
Warranty Card
Yes
RCA Code(Audio), Red/White, 2P
No
RCA Code(Video), Yellow, 1P
Yes
Component Video Cable
No
RCA to Scart Jack Cable
No
Portable In Cable
No
HDMI Cable
Yes
Wireless Rx Kit
No
Microphone (Karaoke)
Yes
A3DSC Mic
No
Song Book
No
Song Disc
No
DLNA Set-up Disc
No
Optical Cable
No
Wall Mount Bracket
No
Carton Box Type – Tip on, Offset, Flexo
Tip on
