Description
Nominal voltage 12.8V
Nominal Capacity 100Ah
Nominal energy 1280Wh
Life Cycles 4000+ (80% DoD for effectively lower total of ownership cost)
Recommended Charge Voltage 14.6V
Recommended Charge Current 20.0A
End of discharge voltage 10.0V
Standard method Charge 20.0A
Discharge 50.0A
Maximum continuous current Charge 50A/100A
Discharge 50A/100A
BMS Cut-Off Voltage Charge <15.6 V (3.9V/Cell)
Discharge >8.0 V (2s) (2.0V/Cell)
Temperature Charge -4 ~ 113 ? (0 ~ 45? )
Discharge -4 ~ 131 ? (-20 ~ 55 ? )
Storage Temperature 23~95 ? (-5~35? )
Shipment voltage ?12.8V
Case Material ABS+PC
Dimension (L x W x H) 320 x 172 x 215 mm
12.6 x 6.7 x 8.5”
Approx. Weight 26.5 lbs (12 kg)
